Series 13
Three-row roller slewing bearing
Three separate raceways: two axial rows and one radial row. The highest load capacity we make, and the standard choice above two metres.
Technical data
Specification range
| Parameter | Range | Remarks |
|---|---|---|
| Outside diameter | 500 – 6,000 mm | Larger on request |
| Section height | 106 – 300 mm | Tallest structure |
| Axial load rating | to 12,000 kN | Static |
| Radial load rating | to 3,000 kN | Static |
| Tilting moment rating | to 5,000 kNm | Static |
| Gear | None / external / internal | Module 6 – 25 |
| Hardening | Raceways induction hardened | Soft zone marked |
Structure
What the structure gives you
Splitting the load paths lets each raceway be optimised: the upper and lower rows take axial load and moment in both directions, the vertical row takes radial load. Capacity per unit of diameter is the highest in the range.
- Independent raceways for axial, radial and moment load
- Highest capacity per unit of diameter
- Preferred for continuous rotation and fatigue-limited duty
- Available with hardened gear teeth for pinion drive
- Split design possible for retrofit around a column
Typical equipment
Ship unloaders, stackers and reclaimers, ladle turrets, deck cranes, mining equipment and large excavators.
Options you can add
- Marine paint system
- Grease purge ports for wash-down
- Split ring for retrofit
- Stainless hardware
- Third-party witness inspection
Send a drawing for the Series 13
Outside diameter, bore, mounting holes, gear module and the load case are enough for a quote. If you are replacing an existing ring, the old part number also works.
