Series 02
Double row ball slewing bearing
Two ball rows share the moment, so tilting capacity climbs above a single-row ring without going to rollers.
Technical data
Specification range
| Parameter | Range | Remarks |
|---|---|---|
| Outside diameter | 300 – 4,000 mm | Larger on request |
| Section height | 80 – 200 mm | |
| Axial load rating | to 4,500 kN | Static |
| Tilting moment rating | to 1,800 kNm | Static |
| Gear | None / external / internal | Module 5 – 18 |
| Clearance | Normal / reduced |
Structure
What the structure gives you
Two raceways with separate ball rows take the axial load and moment in both directions while a third path carries radial load. It sits between the four-point contact ring and the three-row roller in both capacity and cost.
- Higher tilting capacity than a single-row ball ring
- Lower friction than a roller structure
- Good compromise where moment dominates but speed matters
- Available with an eight-point contact option
- Geared or plain
Typical equipment
Cranes, harbour equipment, concrete pumps, wind turbine yaw systems and general industrial turntables.
Options you can add
- Eight-point contact option
- Hardened gear teeth
- Seal set for dusty environments
Send a drawing for the Series 02
Outside diameter, bore, mounting holes, gear module and the load case are enough for a quote. If you are replacing an existing ring, the old part number also works.
